10.7. Dynamic (Ds4) – 4 Liquid Cooled Satellites
Table 11. Triple cabinet Ds4 connected to 4 Liquid Cooled Satellites
Config.
output
ChargEye
connector
Max. cur-
rent
Terminals
DC output Control cable DC input Control cable
1 12 (right) 500 A
Power Unit 1, 2, 3 Satellite 1
OUT 1
CT 1 CAB 1 CT A
OUT 5
2 22 (right) 500 A
Power Unit 1, 2, 3 Satellite 2
OUT 2
CT 2 CAB 1 CT A
OUT 6
3 32 (right) 500 A
Power Unit 1, 2, 3 Satellite 3
OUT 3
CT 3 CAB 1 CT A
OUT 7
4 42 (right) 500 A
Power Unit 1, 2, 3 Satellite 4
OUT 4
CT 4 CAB 1 CT A
OUT 8
10.8. Static (S4) – 1 single Satellite
Table 12. S4 connected to 1 single
Satellite (1 x 500 A/300 A configuration output)
Config.
output
ChargEye
connector
Max. current Terminals
DC output
Control ca-
ble
DC input
Control ca-
ble
1 12 (right) 500 A/300 A Power Unit 1 Satellite 1
OUT 1 CT 1 CAB 1 CT A
OUT 2
OUT 3
OUT 4
