5.2.13.3. Schneider circuit breaker
NOTE
Adjust the switches according to the number of power modules in the cabinet.
NOTE
Use the appropriate factor to include the short circuit value in the selected settings.
NOTE
Turn the rotary switch carefully with a flat screwdriver. Do not rotate the switch 360
degrees.
Select the correct values on the left-hand side rotary switch at the bottom of
the circuit breaker. You should feel when the switch engages on the setting.
Table 4. Schneider circuit breaker (product code NLJF36400U31XTW)
Number of power modules Rotary switch setting (left-hand side)
4 400 A
3 300 A
2 200 A
1 125 A
5.2.14. Installing AC Satellite cables
DANGER
Make sure that AC Satellite is correctly isolated when necessary during installation,
service or maintenance work. Know and obey general and local safety regulations
and procedures. Use adequate personal protection equipment (PPE).
NOTICE
Do not connect the Ethernet cable of AC Satellite to the charging power unit. Doing so
will stop the operation of both units.
NOTE
AC Satellite is not connected to a charging power unit. It is connected directly to the
main power supply.
NOTE
An Ethernet cable between AC Satellite and the local area network (LAN) is optional
but not required.
CHARGING EQUIPMENT FOR ELECTRIC VEHICLES INSTALLATION MANUAL
CONFIDENTIAL – CERTIFIED PARTNERS 102 REV 2.40 EN 04-2024
