3.3.3. Station Charger
NOTE
See the product datasheets for the dimensions and weights of the units. Product
datasheets are available at mediabank.kempower.com.
NOTE
See 9: Unit footprints and clearances for the footprints and required clearances of the
units.
Kempower Station Charger consists of a charging power unit, 1–2 DC vehicle
connectors per cabinet, and a user interface.
Station Charger can have an
additional AC charging socket (option). See the product datasheet for the
available charging cable and vehicle connector types. Station Charger can
be a single or double cabinet unit. Depending on the configuration, Station
Charger can also be connected to 1–2 Kempower Satellites.
Each cabinet can be equipped with 1–4 power modules (C500/500 V and
C800/800 V). One power module provides a maximum of 50 kW charging
power. Charging power management can be dynamic or static, see
3.1:
Charging power management.
CHARGING EQUIPMENT FOR ELECTRIC VEHICLES INSTALLATION MANUAL
CONFIDENTIAL – CERTIFIED PARTNERS 15 REV 2.40 EN 04-2024
