Amphenol charging cable (numbered
wires)
Brugg/Phoenix charging cable
Brugg charging cable (numbered
wires)
REMA charging cable
12.2. CHAdeMO charging cables
NOTICE
Before you connect the signal wires to the mating connector, terminate
the signal wires with ferrules to protect the wires from corrosion.
Connect the nine control signal wires of the CHAdeMO charging cable to the
mating connector:
CHARGING EQUIPMENT FOR ELECTRIC VEHICLES INSTALLATION MANUAL
CONFIDENTIAL – CERTIFIED PARTNERS 153 REV 2.40 EN 04-2024
