3.8. Mounting tube for Satellites (option)
The standard installation flange of the Satellite cannot be used if the
Satellite is installed in a concrete element typically used for e.g. lamp posts.
In this case, order the mounting tube separately as an option.
The optional mounting tube is compatible with concrete elements designed
for posts that have a diameter of 127 mm and it is available in different
lengths. For assistance, contact Kempower Sales Support.
Figure 20. Optional mounting tube for Satellites
Figure 21. Standard installation flange for Satellites
CHARGING EQUIPMENT FOR ELECTRIC VEHICLES INSTALLATION MANUAL
CONFIDENTIAL – CERTIFIED PARTNERS 31 REV 2.40 EN 04-2024
