10.3. Dynamic (Ds4) – 2 double Satellites
Table 7. Ds4 connected to 2 double Satellites (4 x 2 x 200 A configuration output)
Config.
output
ChargEye
connector
Max. current
Terminals
DC output Control cable DC input Control cable
1 12 (right) 2 x 200 A Power Unit 1 Satellite 1
OUT 1 CT 1 CAB 1 CT A
OUT 5
2 11 (left) 2 x 200 A Power Unit Satellite
OUT 2 CT 2 CAB 2 CT B
OUT 6
3 22 (right) 2 x 200 A Power Unit 1 Satellite 2
OUT 3 CT 3 CAB 1 CT A
OUT 7
4 21 (left) 2 x 200 A Power Unit 1 Satellite 2
OUT 4 CT 4 CAB 2 CT B
OUT 8
10.4. Dynamic (Ds4) – 4 single Satellites
Table 8. Ds4 connected to 4 single Satellites (4 x 200 A configuration output)
Config.
output
ChargEye
connector
Max. cur-
rent
Terminals
DC output Control cable DC input Control cable
1 12 (right) 200 A
Power Unit 1 Satellite 1
OUT 1 CT 1 CAB 1 CT A
2 22 (right) 200 A
Power Unit 1 Satellite 2
OUT 2 CT 2 CAB 1 CT A
3 32 (right) 200 A
Power Unit 1 Satellite 3
OUT 3 CT 3 CAB 1 CT A
4 42 (right) 200 A
Power Unit Satellite 4
OUT 4 CT 4 CAB 1 CT A
