1-6 Keysight E5260/E5270 User’s Guide, Edition 6
Getting Started
Step 5. Executing a spot measurement, and starting repeat measurement
1. Press the
Single key to execute the spot measurement.
2. Press the
Repeat key to start the repeat measurement again.
The LCD changes the display as shown below. The following data is just an
example.
Step 6. Changing source output value during repeat measurement
1. Press the
OUT Value key. The cursor appears on the lowest digit of the integral
part of the OUT value. OUT shows the source output value.
2. Press the arrow keys and set the OUT value to 1.500 V. The value is applied to
the output immediately. Then press the
Enter key. The cursor disappears.
Use the Up or Down arrow key to change the output value, and use the Left or
Right arrow key to change the digit the cursor specifies.
The LCD changes the display as shown below. The following data is just an
example.
Meas Value #1 Meas Value #2 Setting Parameter
Stat
OUT: 0.00 V
CPL: 100.0mA
0.00025nA
Remot e
A 2 2
Shift
Lock
Meas
Trigger
Error
Integ
Re pe a t
Ou tput
S-ch
M-ch
Meas Value #1 Meas Value #2 Setting Parameter
Stat
OUT: 1.500 V
CPL: 100.0mA
0.00010nA
Remot e
A 2 2
Shift
Lock
Meas
Trigger
Error
Integ
Re pe a t
Ou tput
S-ch
M-ch
