DIAGNOSTICS Error Codes
10DEC05
DG4825-1
Page
108 of 180
MOTION SYSTEM CONTROL BOARD SYSTEM
30002 - 30033 - MSC BOARD A1: Software malfunctioned
Cause: The MOTION SYSTEM CONTROL BOARD A1 malfunctioned.
Action: Do the checkout for the MOTION SYSTEM CONTROL BOARD A1.
Code Description
30002 The DUPLEX CAM did not make a necessary motion.
30003 The MOTION SYSTEM CONTROL BOARD A1 received a command from
the MASTER CENTRAL PROCESSING UNIT BOARD A2 that was not
correct.
30004 The DUPLEX CAM did not execute the CAM HOME operation.
30005 The DUPLEX CAM did not execute the CAM PINCH CASSETTE operation.
30006 The DUPLEX CAM did not execute the CAM UNLATCH CASSETTE
operation.
30007 The DUPLEX CAM did not execute the “CAM LATCH CASSETTE operation.
30008 The DUPLEX CAM did not execute the CAM UNPINCH CASSETTE
operation.
30009 The DUPLEX CAM did not execute the CAM JOG operation.
30011 The DRIVE ROLLERS did not execute the necessary motion.
30012 A command that was not correct was sent to the DRIVE ROLLER.
30013 The SLOW SCAN AY detected a signal that was not correct.
30014 An operation of DRIVE ROLLER did not complete in the time allowed.
30015 A status of the SENSOR that was not correct was detected by the software
during operation of the DRIVE ROLLER.
30016 The EJECT CASSETTE operation did not complete in the time allowed.
30017 The software determined that the CASSETTE ENTRY SENSOR S1
malfunctioned.
30018 The software determined that the CASSETTE REAR SENSOR S3
malfunctioned.
30019 The software determined that the CASSETTE LOAD SENSOR S2
malfunctioned.
