DIAGNOSTICS Checkout Procedures

10DEC05

DG4825-1

Page

129 of 180

PLATE PRESENT SENSOR S5

1 At the “Service System Diagnostic”

screen, touch [Individual Component

Control].

2 Block the PLATE PRESENT SENSOR

S5.

H194_1034AC

IR Detection Stick

H194_1034ACA

PLATE

PRESENT

SENSOR S5

IR PHOSPHOR PROBE

TL-2579
