Kodak DirectView CR 825 User Manual

DIAGNOSTICS Checkout Procedures
10DEC05
DG4825-1
Page
125 of 180
11 If:
• DUPLEX CAM does not move, do the checkout for the CAM MOTOR M1
• HOOKS are not in the up position, do the checkout HOOKS on the EXTRACTION
BAR
• EXTRACTION BAR is not in the home position, do EXTRACTION BAR HOME
POSITION
12 Check the status of the SENSORS and LEDs.
13 If the status of a SENSOR does not match the table, do the corresponding checkout.
14 Press [PINCH POSITION].
15 If:
• DUPLEX CAM does not move, do the checkout for the CAM MOTOR M1
• HOOKS are not in the down position, do the checkout HOOKS on the EXTRACTION
BAR
• EXTRACTION BAR is not in the home position, do EXTRACTION BAR HOME
POSITION
16 Check the status of the SENSORS and LEDs.
SENSOR Status LED Checkout
EXTRACTION BAR SENSOR
S9
X DS28
illuminated
EXTRACTION BAR SENSOR
S9
CAM INNER SENSOR S10 X DS26
illuminated
CAM SENSORS S10 and S11
CAM OUTER SENSOR S11 DS27 not
illuminated
