Kodak DirectView CR 825 User Manual

DIAGNOSTICS Checkout Procedures
10DEC05
DG4825-1
Page
124 of 180
5 If the status of a SENSOR does not match the table, do the corresponding checkout.
6 Touch [UNPINCH POSITION].
7 If:
• DUPLEX CAM does not move, do the checkout for the CAM MOTOR M1
• HOOKS are not in the down position, do the checkout for the HOOKS on the
EXTRACTION BAR
• EXTRACTION BAR is not in the home position, do EXTRACTION BAR HOME
POSITION
8 Check the status of the SENSORS and LEDs.
9 If the status of a SENSOR does not match the table, do the corresponding checkout.
10 Touch [HOOKS UP POSITION].
SENSOR Status LED Checkout
EXTRACTION BAR SENSOR
S9
X DS28
illuminated
EXTRACTION BAR SENSOR
S9
CAM INNER SENSOR S10 X DS26
illuminated
CAM SENSORS S10 and S11
CAM OUTER SENSOR S11 X DS27
illuminated
SENSOR Status LED Checkout
EXTRACTION BAR SENSOR
S9
X DS28
illuminated
EXTRACTION BAR SENSOR
S9
CAM INNER SENSOR S10 X DS26
illuminated
CAM SENSORS S10 and S11
CAM OUTER SENSOR S11 X DS27
illuminated
