DIAGNOSTICS Using the Diagnostics
10DEC05
DG4825-1
Page
14 of 180
Table 3 Component Adjustments
BUTTON Description
[Set Extraction Bar Home]
Important
For the procedure, see EXTRACTION BAR HOME
POSITION.
Allows you to set and check the home position of the
EXTRACTION BAR:
• [FINE NUDGE UP]
• [FINE NUDGE DOWN]
• [COARSE NUDGE UP]
• [COARSE NUDGE DOWN]
• [SAVE] - Sets the selected home position
• [CANCEL] - Resets the home position to the last
recorded value
[Extraction Bar Positions] Allows you to move the EXTRACTION BAR to:
• [HOME]
• [UPPER PLATE GUIDE POSITION]
• [LOWER PLATE GUIDE POSITION]
• [ERASE]
• [RETURN TO HOME]
• [NUDGE UP]
• [NUDGE DOWN]
