DIAGNOSTICS Using the Diagnostics
10DEC05
DG4825-1
Page
15 of 180
[CAM Position Actuation]
Important
See the checkout of the DUPLEX CAM.
Allows you to check the status of the CASSETTE
HANDLING AY by rotating the DUPLEX CAM to:
• [HOME CAM]
• [HOOKS UP POSITION]
• [PINCH POSITION]
• [UNPINCH POSITION]
• [UNLATCH POSITION]
• [LATCH POSITION]
Allows you to reset the DUPLEX CAM after jams:
• [FINE JOG FORWARD]
• [FINE JOG REVERSE]
• [COARSE JOG FORWARD]
• [COARSE JOG REVERSE]
• [Return PLATE to CASSETTE]
• [HOME SLOW SCAN]
[Slow Scan Current Calibration]
Important
For the procedure, see Calibration for the CR 825/850
SYSTEM.
Completes the calibration of the SLOW SCAN MOTOR for
the correct current at all 3 phases of the MOTOR.
[Slow Scan Preload
Adjustment]
Moves the SLOW SCAN AY. This allows you to make
adjustments to the SLOW SCAN AY.
BUTTON Description
