DIAGNOSTICS Using the Diagnostics
10DEC05
DG4825-1
Page
29 of 180
5 Check the status of the SENSORS.
6 Does the status of the SENSORS match?
7 Touch [LOAD PLATE TO SCAN Position].
8 Check the status of the SENSORS.
9 Does the status of the SENSORS match?
10 Touch [SCAN (without laser)].
Yes No
Continue with Step 7. 1. Check the error logs. See Checking the Error Logs.
2. See the Error Codes to determine the possible cause
and action for the problem.
3. Continue with Step 7.
Yes No
Continue with Step 10. 1. Check the error logs. See Checking the Error Logs.
2. See the Error Codes to determine the possible cause
and action for the problem.
3. Continue with Step 10.
To Next Page
