4 CANopen Communciation Profile
This chapter describes the basic services and communication objects of the CANopen com-
munication profile DS 301, which are used in the S300/S700.
It is assumed that the basic operating functions of the communication profile are known, and
available as reference documentation.
4.1 General description of CAN
The transmission method that is used here is defined in ISO 11898 (Controller Area Network CAN
for high-speed communication).
The Layer-1/2 protocol (Physical Layer/Data Link Layer) that is implemented in all CAN modules
provides, amongst other things, the requirements for data.
Data transport or data request is made by means of a data telegram (Data Frame) with up to 8
bytes of user data, or by a data request telegram (Remote Frame).
Communication objects (COBs) are labeled by an 11-bit Identifier (ID) that also determines the pri-
ority of objects.
A Layer-7 protocol (Application Layer) was developed, to decouple the application from the com-
munication. The service elements that are provided by the Application Layer make it possible to
implement an application that is spread across the network. These service elements are
described in the CAN Application Layer (CAL) for Industrial Applications.
The communication profile CANopen and the drive profile are mounted on the CAL.
The basic structure of a communication object is shown in the following diagram:
S
O
M
COB-ID
R
T
R
CTRL Data Segment CRC
A
C
K
EOM
SOM Start of message
COB-ID Communication Object Identifier (11-bit)
RTR Remote Transmission Request
CTRL Control Field (e.g. Data Length Code)
Data Segment 0 ... 8 byte (Data-COB)
0 byte (Remote-COB)
CRC Cyclic Redundancy Check
ACK Acknowledge slot
EOM End of message
S300-S700 CANopen | 4 CANopen Communciation Profile
Kollmorgen | kdn.kollmorgen.com | December 2019 15
