8 Commissioning/Shutdown
119 of 212
PumpDrive 2
Table92: Parameters for analog inputs 1 and 2
Parameter Description Possible settings Factory setting
3-8-1-1 Analog Input 1 Signal
Sensor signal at analog input 1
▪ OFF
▪ 4…20 mA
▪ 2…10 V
▪ 0…20 mA
▪ 0…10 V
OFF
3-8-1-2 Analog Input 1 Function
Function of analog input1. Internal
operating values cannot be used as an
actual value source.
▪ OFF
▪ Setpoint/Control Value
(Auto)
▪ Control Value (Manual)
▪ Suction Pressure
▪ Discharge Pressure
▪ Differential Pressure
▪ Flow Rate
▪ Level
▪ Temperature
▪ Suction Pressure_Internal
▪ Discharge Pressure_Internal
▪ Differential
Pressure_Internal
OFF
3-8-1-3 Analog Input 1 Lower Limit Minimum limit of measuring
range (dependent on the analog
input function selected)
0
3-8-1-4 Analog Input 1 Upper Limit Maximum limit of measuring
range (dependent on the analog
input function selected)
0
3-8-2-1 Analog Input 2 Signal
Sensor signal at analog input 2
▪ OFF
▪ 4…20 mA
▪ 2…10 V
▪ 0…20 mA
▪ 0…10 V
OFF
3-8-2-2 Analog Input 2 Function
Function of analog input2. Internal
operating values cannot be used as an
actual value source
▪ No Function
▪ Setpoint/Control Value
(Auto)
▪ Alternative Setpoint/Control
Value (Auto)
▪ Control Value (Manual)
▪ Suction Pressure
▪ Discharge Pressure
▪ Differential Pressure
▪ Flow Rate
▪ Level
▪ Temperature
▪ Suction Pressure_Internal
▪ Discharge Pressure_Internal
▪ Differential
Pressure_Internal
OFF
