8 Commissioning/Shutdown
89 of 212
PumpDrive 2
Parameter Description Possible settings Factory setting
3-4-3-3 Flow Rate Q_2 Minimum to maximum flow rate Pump-specific
3-4-3-4 Flow Rate Q_3 Minimum to maximum flow rate Pump-specific
3-4-3-5 Flow Rate Q_4 Minimum to maximum flow rate Pump-specific
3-4-3-6 Flow Rate Q_5 Minimum to maximum flow rate Pump-specific
3-4-3-7 Flow Rate Q_6 Minimum to maximum flow rate Pump-specific
3-4-3-8 Flow Rate Q_
opt
Minimum to maximum flow rate Pump-specific
3-4-3-9 Pump Input Power P_0 Minimum to maximum flow rate Pump-specific
3-4-3-10 Pump Input Power P_1 Minimum to maximum flow rate Pump-specific
3-4-3-11 Pump Input Power P_2 Minimum to maximum flow rate Pump-specific
3-4-3-12 Pump Input Power P_3 Minimum to maximum flow rate Pump-specific
3-4-3-13 Pump Input Power P_4 Minimum to maximum flow rate Pump-specific
3-4-3-14 Pump Input Power P_5 Minimum to maximum flow rate Pump-specific
3-4-3-15 Pump Input Power P_6 Minimum to maximum flow rate Pump-specific
3-4-3-16 Head H_0 00,00...1000,00 Pump-specific
3-4-3-17 Head H_1 00,00...1000,00 Pump-specific
3-4-3-18 Head H_2 00,00...1000,00 Pump-specific
3-4-3-19 Head H_3 00,00...1000,00 Pump-specific
3-4-3-20 Head H_4 00,00...1000,00 Pump-specific
3-4-3-21 Head H_5 00,00...1000,00 Pump-specific
3-4-3-22 Head H_6 00,00...1000,00 Pump-specific
3-4-3-23 NPSH_0 00,00...1000,00 Pump-specific
3-4-3-24 NPSH_1 00,00...1000,00 Pump-specific
3-4-3-25 NPSH_2 00,00...1000,00 Pump-specific
3-4-3-26 NPSH_3 00,00...1000,00 Pump-specific
3-4-3-27 NPSH_4 00,00...1000,00 Pump-specific
3-4-3-28 NPSH_5 00,00...1000,00 Pump-specific
3-4-3-29 NPSH_6 00,00...1000,00 Pump-specific
3-4-3-30 Low Flow Limit Flow Rate in % Q 0...100 Pump-specific
8.8.2 Protective functions
8.8.2.1 Activating/deactivating thermal motor protection
Thermal overload results in immediate tripping and an alert message is output.
Restarting will only be possible after the motor has cooled down sufficiently. The
stop threshold value is set at the factory for monitoring with a PTC sensor or a
thermal circuit breaker. If other thermocouples are used, the value has to be set by
KSB Service.
NOTE
Thermal motor protection cannot be activated/deactivated while the motor is in
operation.
Table62: Thermal motor protection
Parameter Description Possible settings Factory setting
3-2-3-1 PTC Data Analysis
Motor temperature monitoring
▪ OFF
▪ ON
ON
3-2-3-2 Thermal Motor Protection Behaviour
Behaviour for detection of excessive motor
temperature
▪ Non-self-acknowledging
▪ Self-acknowledging
Non-self-acknowledging
