8 Commissioning/Shutdown
71 of 212
PumpDrive 2
Table44: System start parameters
Parameter Description Possible settings Factory setting
1-3-1 System Start / Stop
This function is used to start the system.
▪ Start
▪ Stop
Stop
3-8-6-1 Digital Input 1 Function
Configurable function of digital input 1
(ðSection8.10.1,Page114) System Start
Alternative control value and setpoint
If the (manual-mode) control value is defined at the control panel or via the analog
input, an alternative (manual-mode) control value can be activated by way of the
time or a digital input. Using this function, it is possible to define a different setpoint
for the night than for the day (setback operation), for example.
NOTE
If a fixed speed is defined via a digital input, an alternative specification for the
(manual-mode) control value cannot be configured.
Table45: Alternative control value and setpoint parameters
Parameter Description Possible settings Refers to Factory setting
1-3-9-1 Alternative Setpoint (Closed-loop
Control)
Alternative configurable setpoint
(can be activated via time or DIGIN;
DIGIN has priority). This parameter
is disabled if the setpoint is
specified via DIGIN/ANIN.
Otherwise, the setpoint source is
selected via the Control Point
parameter (Local/Field Bus).
Minimum to maximum
limit of measuring range
3-11 0.00
1-3-9-2 Alternative Control Value (Open-
loop Control)
Alternative configurable control
value for speed in open-loop control
mode
Minimum motor speed to
maximum motor speed
3-11 500 rpm
1-3-9-3 Start of Alternative Setpoint/
Control Value
Start of toggle from setpoint/control
value to alternative setpoint/control
value
00:00…23:59 00:00
1-3-9-4 End of Alternative Setpoint/
Control Value
End of toggle from setpoint/control
value to alternative setpoint/control
value
00:00…23:59 00:00
To switch from the current setpoint or control value to an alternative setpoint or
control value via a digital input, the digital input must be set to "Alternative
Setpoint/Control Value Active" (ðSection8.10.1,Page114) .
If the setpoint or control value is specified or defined via a/the field bus module, the
control point must also be set to Local to activate the alternative setpoint or control
value.
