4 Operation
20 of 212
PumpDrive 2
4.1.2.3.2 Setting the control panel
Table18: Parameters for setting the control panel
Parameter Description Possible settings Factory setting
3-1-2-1 Operating Values on Main Screen
Display of current operating values on the main
screen
Main screen selection list -
3-1-2-2 Control Keys Require Login
Direct access to the MAN, OFF, AUTO and FUNC
operating keys can be disabled via this parameter.
▪ OFF
▪ ON
OFF
3-1-2-3 Function Key Assignment
Assigning a freely selectable function to the FUNC
key
▪ No Function
▪ System Start / Stop
▪ Setpoint (Closed-loop
Control)
▪ Control Value (Open-loop
Control)
▪ Alternative Setpoint (Closed-
loop Control)
▪ Alternative Control Value
(Open-loop Control)
▪ Immediate Pump
Changeover
▪ Immediate Functional Check
Run
▪ Language
▪ Fixed Speed 1
▪ PumpMeter Upload
▪ Remote/Local Control Point
Language
3-1-2-4 Display Contrast
Configurable contrast for the display
0...100 50
3-1-2-5 Display Backlight
Configuring the display backlight
▪ OFF
▪ ON
▪ Automatic
Automatic
3-1-2-6 Display Backlight Duration
Duration of display backlight on period in
automatic mode
0...600 30
Operating Values on Main
Screen
Up to 4operating values are simultaneously displayed on the main screen. An
operating value is displayed in large format with the associated parameter name,
parameter number and unit. Three (3) operating values are displayed in smaller
format with the associated unit. The arrow keys can be used to cycle through the
operating values. Each operating value passes through all display areas. Up to
10operating values can be selected from the predefined list for the display. The
sequence of the selection list determines the sequence of the operating values on the
main screen. If more than 4parameters are selected, the hidden parameters are also
cycled through in the background.
Selecting operating values for the main screen
1. Open parameter 3-1-2-1 in the Settings menu.
2. Using the arrow keys, select the operating value to be displayed from the list.
3. Press OK key.
4. Select additional, required operating values from the list and confirm by
pressing the OK key.
