6 Description
27 of 212
PumpDrive 2
Size Nominal electrical power Nominal output current Mains-side input current
[kW] [A] [A]
E 45 97 99
55 120 122,4
6.5 Technical data
Table23: Technical data of frequency inverter
Characteristic Value
Mains supply
Mains voltage
5)
3 ~ 380VAC - 10% to 480VAC +10%
Voltage difference between the three phases ±2% of the supply voltage
Mains frequency 50 - 60Hz ± 2 %
Mains types TN-S, TN-CS, TN-C, TT and IT mains (to IEC/EN60364)
Output data
Frequency inverter output frequency 0 - 70 Hz for asynchronous motors
0 - 140Hz for KSBSuPremE
PWM carrier frequency Range: 2 - 8 kHz
(Factory setting: 4kHz)
Phase rate of rise dv/dt
6)
5000 V/µs max. (depending on the size of the frequency
inverter)
Peak voltages 2×1,41×V
eff
Lines with a high current-carrying capacity can cause the
voltage to increase up to double the value.
Frequency inverter data
Efficiency 98 % - 95 %
7)
Noise emissions Sound pressure level of pump used + 2.5dB
8)
Environment
Enclosure IP55 (to EN 60529)
In-service ambient temperature -10°C to +50°C
In-storage ambient temperature -10 °C to +70 °C
Relative humidity Operation: 5% to 85% (non-condensing)
Storage: 5% to 95%
Transport: 95%max.
Installation altitude < 1000m above MSL, or 1 % power derating per additional
100m
Vibration resistance 16.7m/s
2
max. (to EN60068-2-64)
Fluid temperature -30°C to +140°C
EMC
Frequency inverter ≤11kW EN61800-3 C1/EN55011 Class B/cable length ≤ 5m
Frequency inverter ≥ 15 kW EN 61800-3 C2/EN 55011 Class A, Group 1/cable length ≤50m
Mains feedback Integrated line chokes
Inputs and outputs
Internal power supply unit 24V ± 10 %
Maximum load 600mA DC max., short-circuit and overload-proof
5) If the mains voltage is low, the nominal torque of the motor will be lower.
6) The phase rate of rise (dv/dt) depends on the line capacity.
7) The efficiency at the nominal point of the frequency inverter varies between 98 percent for high power outputs and
95percent for low outputs, depending on the inverter's nominal power.
8) The values are for orientation purposes only. The value refers to the nominal duty point (50Hz) only. Also refer to the
pump's noise characteristics. They, too, are documented for nominal duty operation. Other values may occur during
variable speed operation.
