4.1.2.1 Menu: Operation
The Operation section contains all information required for operating the machine
and the process. This includes:
▪ Login to device with password
▪ Operating and measured values for motor, frequency inverter, pump and system
▪ Setpoints and control values
▪ Energy meter and operating hours
4.1.2.1.1 Access levels
Three access levels have been defined to prevent accidental or unauthorised access to
frequency inverter parameters:
Table11: Access levels
Access level Description
Standard (No Login) Access without password entry.
Customer Access level for the expert user with access to all parameters required for
commissioning
Customer service Access level for service personnel.
If a parameter's access level is not explicitly specified, the parameter is always
assigned the customer access level.
Table12: Access level parameters
Parameter Description Possible settings Factory setting
1-1-1 Customer Login
Log in as customer
0000...9999 0000
1-1-2 Service Login
Log in for access to special parameters for KSB
Service
0000...9999 -
1-1-4 Logout
Log out of all access levels
Run -
NOTE
If no keys are pressed for ten minutes, the system will automatically return to the
standard access level.
The password can be changed after entering the factory default password.
Table13: Parameters for changing passwords
Parameter Description Possible settings Factory setting
1-1-5 Customer Access ID
Changing the customer access ID
0000...9999 -
1-1-6 Service Access ID
Changing the service access ID
0000...9999 -
4.1.2.1.2 Operating values for input and output signals
The status of the digital inputs/relay outputs is displayed via the Digital Inputs
(1-2-4-6) and Digital Outputs (1-2-4-7) parameters.
Table14: Example of status of digital inputs (1-2-4-6). 24V is applied to digital input 1: System Start
Optional IO card Standard
Digital input DI8 DI7 DI6 DI5 DI4 DI3 DI2 DI1
Bit pattern on display 0 0 0 0 0 0 0 I
