KSB PumpDrive 2 - Assignment of Keys

4 Operation
15 of 212
PumpDrive 2
5 Display of operating status
6 Display of the current operating mode
7 Parameter number of the operating value displayed in the centre
8 Name of the operating value displayed in the centre
Table9: Assignment of keys
Key Function
Operation menu key
Diagnosis menu key
Settings menu key
Information menu key
Arrow keys:
▪ Move up/down in the menu options.
▪ Increase/decrease the value displayed when you are entering numerals. (When an arrow
key is pressed and held down, the response repeats in ever shorter intervals.)
ESC
Escape key:
▪ Delete/reset entry
(the entry is not saved).
▪ Move up one menu level.
OK
OK key:
▪ Confirm settings.
▪ Confirm menu selection.
▪ Move to the next digit when entering numerals.
▪ Message display: Acknowledge alert.
▪ Measured value display: Go to Favourites menu.
?
Help key:
▪ Displays a help text for each selected menu option.
MAN
MAN operating key:
▪ Starts the frequency inverter in manual operating mode.
OFF
OFF operating key:
▪ Stops the frequency inverter.
AUTO
AUTO operating key:
▪ Switches to automatic operating mode.
FUNC
FUNC operating key:
▪ Parameterisable function key
Manual mode via control panel
NOTE
After a power failure, the frequency inverter reverts to the OFF operating mode.
Manual mode must be restarted.
