8 Commissioning/Shutdown
121 of 212
PumpDrive 2
Table93: Parameters for relay1
Parameter Description Possible settings Factory setting
3-8-9-1 Relay 1 Function
Selectable messages via relay 1
▪ None
▪ AUTO operating mode
▪ RUN operating status
▪ AUTO/SLEEP operating status
▪ Warning
▪ Alert
▪ Alert or Warning
▪ No alert
▪ Dynamic overload protection
▪ Current too high
▪ Current too low
▪ Frequency too high
▪ Frequency too low
▪ Power too high
▪ Power too low
▪ Actual value = setpoint
Alert
3-8-9-2 Time Delay ON
Period of time during which the
event selected must be continually
available until the relay is set.
0,0 – 10,0s 0,5s
3-8-9-3 Time Delay OFF
Period of time for which the
event selected must have gone
before the relay is reset
0,0 – 10,0s 0,5s
