10 Parameter List
148 of 212
PumpDrive 2
Parameter Description Help text Possible settings Unit Factory setting
3-6-5 Manual Mode
3-6-5-1 Fixed Speed 1 Fixed speed selectable via digital inputs 3-2-2-1 … 3-2-2-2 0
3-6-5-2 Fixed Speed 2 Fixed speed selectable via digital inputs 3-2-2-1 … 3-2-2-2 0
3-6-5-3 Fixed Speed 3 Fixed speed selectable via digital inputs 3-2-2-1 … 3-2-2-2 0
3-6-6 Digital Potentiometer
3-6-6-1 Setpoint Change
Increment
The parameter defines by what value per
pulse at the digital input the setpoint is
increased or decreased in automatic mode.
Minimum to maximum limit of value range
set
Dependent on the
unit set
0,10
3-6-6-2 Speed Change Increment The parameter defines by what value per
pulse at the digital input the manual-mode
control value for a single-pump and
multiple pump system is increased or
decreased.
0 … 1000 rpm 10
3-6-6-3 Interval Time for automatic change in value for
continuously present signal
0,0 … 10,0 s 0,5
3-7 Multiple Pump
Configuration
3-7-1 Role in Multiple Pump
System
Selecting the role of the frequency inverter
in a multiple pump configuration. The
active master control device is responsible
for starting and stopping pumps, as well as
for open-loop and closed-loop control. All
input variables required for open-loop or
closed-loop control must be connected to
the master control device and all redundant
master control devices. The redundant
master control device which is to serve as
active master control is selected
automatically based on a configurable
transfer time. Auxiliary control and
redundant master control devices receive
the manual-mode control value from the
master control device.
▪ Master Control
▪ Auxiliary Control
Master Control
3-7-2
Maximum Number of
Pumps Running
Maximum number of pumps running
simultaneously in a multiple pump
configuration
1…6 1
3-7-3 Start / Stop
3-7-3-1 Min. Time Start Minimum period of time between two
starts
0.0…600,0 s 10,0
