2 System installation
2 System installation
Detach the cable ties on the rear wall.
Detach cable ties
Unscrew the connectors from the rear wall.
Unscrew connectors
10.) Take off the cladding cover
Unscrew the screws of the hinge.
Unscrew the hinge
Unscrew the hinge from the cover.
Take off the cover.
Unscrew the cover hinge
11.) Dismount the junction box
Loosen the 4 fixing screws and unhook the junction box from the front.
Unhook the junction box
MA-Easyfire 10.2008_EN.indd 18MA-Easyfire 10.2008_EN.indd 18 30.03.2009 13:29:51 Uhr30.03.2009 13:29:51 Uhr

KWB Easyfire Specifications

General

Fuel Type	Wood pellets
Cleaning System	Automatic heat exchanger cleaning
Emission Class	5
Nominal Heat Output	10 kW
Type	Pellet heating system
Ash Removal	Automatic
Heating capacity	10 kW
Hopper capacity	15 kg
Flue diameter	130 mm
