© KWB – Kraft und Wärme aus Biomasse GmbH IM Easyfire 10/2008 Page 17
2 System installation
2 System installation
Pull the burner straight out of the boiler.
Dismantle the burner
9.) Dismount the cabling
Dismount the plug-in panel.
Dismantle the plug-in panel
Disconnect all plug-type connectors from the boiler I/O module.
Thread these connectors through the penetration rings.
Disconnect the boiler I/O
Dismount the holder bracket for main switch, chimney sweep button and
safety thermostat.
Switch panel
Disconnect the earth connections on the corner points.
Disconnect the ground connections
MA-Easyfire 10.2008_EN.indd 17MA-Easyfire 10.2008_EN.indd 17 30.03.2009 13:29:50 Uhr30.03.2009 13:29:50 Uhr

KWB Easyfire Specifications

General

Fuel Type	Wood pellets
Cleaning System	Automatic heat exchanger cleaning
Emission Class	5
Nominal Heat Output	10 kW
Type	Pellet heating system
Ash Removal	Automatic
Heating capacity	10 kW
Hopper capacity	15 kg
Flue diameter	130 mm
