General Maintenance 115
Figure 3-143
Exterior guide
10. Remove all 6 wear pads (3 each in both upper and lower sections of the rail) and the sliding shoe
(see Figure 3-144).
Figure 3-144
Wear pads and sliding shoe
Wear pads
(6)
Sliding shoe
