Preparations
Names of the components
- 10 -
Mode dial (→25)
Use to select the recording mode.
Flash (→75)
Self-timer indicator (→89) /
AF Assist Lamp
(→136)
Lights up/flashes when the self-timer is used or
when the Auto Focus function is operated in dark
locations.
Control ring (→27)
Allows controlling different (previously selected)
functions during recording such as changing the
focal length.
Lens barrel
Speaker
(→55)
Card/Battery door (→14, 19)
Open to insert and remove card and/or battery.
Lock/release slider (→14, 19)
Microphones (→26, 40)
Zoom lever (→71)
Use change the focal length / enlarge or minimize
a subject.
[OFF/ON] button
Use to turn the camera on and off.
Shutter button
Lens
Tripod thread
(→237)
Do not attach to a tripod using screws longer than 5.5mm /
7
/
32
″.
Doing so may damage the camera.
(Top)
(Bottom)
●
