6-16 Operating Instructions
D-H023.0906EN
innovators in agriculture
3. Select [ENTER].
4. Select [OK].
6.8.3 Stop Sampling
1. Stop the sampling in the T4C software (refer to the T4C manual).
2. Select Tab [Sampling].
3. Select [Turn sampling off].
4. When the Confirm stop sampling pop-up window appears, select
[Stop] .
5. When the screen changes to Cows are not marked for sampling,
"Disconnect Shuttle now, when ready press close", select [Close] in
the field Valve sampling.
6. Remove the nipple (3, fig. 21,
page 6-16) and the hose (4) from the
knee (2).
7. Install the plug (1) in the hole in the knee.
8. Remove the nipple (3) from the hose (4).
9. Remove the hose (4) from the sample unit (5).
10. In the field Valve sampling, select:
• [Open]
• [Close].
11. Make sure the tab [Sampling] disappears.
Figure 21. Connect the sampling tube from the Shuttle (backside view)
