7-40 Maintenance
D-H023.0906EN
innovators in agriculture
Figure 53. Make an incision in the twin tube
7.9.3 Replace the Filter Element of the Single Filter
7.9.3.1 Replace the Filter Element of the Single Filter
1. On the X-Link, select:
• Button
to open the quick launch buttons bar.
•
.
2. When the pop-up window with the text Continue milk filter
exchange?> opens, select [OK].
A pop-up window opens with the text The milk filter is being
prepared for exchange and the button changes to:
3. Wait until the text in the pop-up window changes to The milk filter
is ready for exchange.
4. Hold the filter housing and remove the cap.
5. Remove the filter housing.
6. Remove the filter sock and the spring from the filter housing.
7. Examine the filter sock for flakes that indicate mastitis in the herd.
8. Remove the filter ring and the filter sock from the spring.
9. Rinse the filter ring and the filter housing with clean water.
10. Make sure the thread and the top of the filter housing are clean
and dry.
11. Slide the spring into a new filter sock and fold the sock top into the
top of the spring.
12. Install the filter ring on the spring.
