Maintenance 7-41
D-H023.0906EN
innovators in agriculture
13. Slide the filter sock and the spring in the filter housing until
approximately 15 cm (5.90 in) of the filter sock is outside the filter
housing.
14. Hold the filter housing in position below the milkline and push the
filter sock fully into the tapered part of the milkline.
15. Connect the cap to the filter housing and tighten the cap hand-
tight.
16. Hold the filter housing (6, fig. 54, page 7-42) and remove the cap
(1).
17. Remove the filter housing (6).
18. Remove the filter sock (5) and the spring (3) from the filter housing.
19. Examine the filter sock for flakes that indicate mastitis in the herd.
20. Remove the filter ring (2) and the filter sock (4) from the spring (3).
21. Rinse the filter ring and the filter housing with clean water.
22. Make sure the thread and the top of the filter housing are clean
and dry.
23. Slide the spring into a new filter sock and fold the sock top (3) into
the top of the spring.
24. Install the filter ring (2) on the spring.
25. Slide the filter sock and the spring in the filter housing until
approximately 15 cm (5.90 in) of the filter sock is outside the filter
housing.
26. Hold the filter housing in position below the milkline and push the
filter sock fully into the tapered part of the milkline.
27. Connect the cap to the filter housing and tighten the cap hand-
tight.
28. Select [Milk filter has been exchanged].
29. The pop-up window closes and the button changes to:
.
