Specifications 3-1
D-H023.0906EN
innovators in agriculture
3. SPECIFICATIONS
3.1 Milking Robot
Dimensions and Weight
• Height: 229 cm (90.16 in)
• Length: 423 cm (166.54 in)
• Width:
• Arm extended: approx. 198 cm (77.95 in)
• Arm retracted: approx. 180 cm (70.87 in).
• Weight: approx. 1550 kg (3410 lb.).
Refer to the Diagrams in chapter 10 for the complete dimensions of the
ASTRONAUT A3 Next.
Operation Area
The minimum areas necessary for operation of the milking robot are:
• Cow side (for the gates): 130 cm (51.2 in)
• Robot arm side (with arm extended): 160 cm (63 in)
• No operation areas are necessary at each end of the milking robot.
3.2 Compressor Unit
Note:
Please refer to the documentation of the Compressor for more information.
The compressor unit must provide oil free compressed air. Lely
recommends one of the following compressor units:
• Atlas Copco SF2 P8-SD6, or
• Atlas Copco SF4 P8-SD6, or
• Atlas Copco SF8 P8-SD6.
Dimensions and weight
• Dimensions SF2, SF4 (including air drier):
• Depth: 60 cm (2 ft)
• Width: 130 cm (4 ft, 2 in)
• Height: 155 cm (5 ft).
• Dimensions SF8 (including air drier):
• Depth: 78.4 cm (2 ft, 7 in)
• Width: 157.6 cm (5 ft, 2 in)
• Height: 105 cm (3 ft, 5 in).
• Weight:
• SF2: approx. 218 kg (480 lb)
• SF4: approx. 232 kg (511 lb)
• SF8: approx. 390 kg (860 lb).
