LELY ASTRONAUT A3 Next User Manual

Maintenance 7-7
D-H023.0906EN
innovators in agriculture
3. Remove the middle cover (fig. 29, page 7-10) from its position on
the upper cover.
4. Push the middle cover (2, fig. 27,
page 7-9) with its pins into the
corresponding holes (1) in the frame and push it down.
Upper cover
Note:
Both upper and middle cover must be opened/removed to get access to the
multiple function box.
1. Open or close the upper cover (fig. 28, page 7-9).
Figure 24. Remove the middle cover
