7-24 Maintenance
D-H023.0906EN
innovators in agriculture
7. In the field Cord cups, select [Fixed] for the applicable teat cup.
8. Make sure the cup cord (3, fig. 39,
page 7-26) is put through the
washer (2).
9. Pull the cup cord on the mothership side. Make sure the teat cup is
firmly in the tilt cup.
10. Use a ballpoint pen to mark (1) the cup cord where it goes into the
mothership.
11. In the field Cord cups, select [Loose] for the applicable teat cup.
12. Tie a slip knot (1, fig. 40,
page 7-26) in the cup cord just behind the
mark (3).
13. In the field Cord cups, select [Fixed] for the applicable teat cup.
14. Make sure the teat cup is firmly in the tilt cup.
15. Put the cup cord(s) into the mothership (2).
16. Put the cup cord(s) into the mothership (2).
Close-up
1. Install the mothership cover (page 7-13).
2. Install the lower arm cover.
3. Move the robot arm to the home position.
4. Put the milking robot in operation with the X-Link (page 6-1).
