4-32 Description and Operation
D-H023.0906EN
innovators in agriculture
Name Description
(De)activate
supervision
To tell the T4C that supervision must be (de)activated (this setting is stored
after milking is completed).
Skip Lelywash/short
rinse
To cancel the planned Lelywash or short rinse.
4.4.1.2 Navigation in the X-Link Menu
When you navigate through the X-Link menu, selected items are
displayed as follows:
• Selected tabs: come to the front
• Selected menu items: change to a blue rectangle with text
• Selected buttons: appear pushed in.
4.4.1.3 Tabs
Information and menus on the X-Link are displayed on the following
tabs:
• Process
• Settings
• Test
• Indications
• System
• T4C.
Tab name: Process
During operation of the milking robot the display of the process tab is
continually refreshed to show the current status of the following items:
• The status of the box
For example: Waiting for visit.
• Cow status
For example: Cow name, cow number and cow tag.
• General milking status
For example: Pre treatment.
• Detailed milking status
For example: Color information and temperature.
• The status of the milk destination
For example: M4Use.
• The status of feeding
For example: The quantity of food eaten by the cow.
• The status of cow destination
Where does the cow go to after milking.
• The status Scale
For example: Current measurement weight of the scale.
• The status of cleaning
For example: Status of local cleaning and use of detergent.
