Lenovo ThinkSystem SR650 V2 - Page 171

Front bays Mid bays Rear bays
CPUs Controllers
S/S
3.5"
Any
3.5"
S/S
3.5"
NVMe
2.5"
S/S
2.5"
S/S
3.5"
8 0 0 0 0 0
1 or 2
OB SATA
1 or 2 1 x RAID/HBA 8i
12 0 0 0 0 0
1 or 2
OB SATA
1 or 2 1 x RAID/HBA 16i
12 0 0 0 0 2
1 or 2
OB SATA + OB SATA
1 or 2 1 x RAID/HBA 16i
1 or 2 1 x RAID/HBA 16i + OB SATA
1 or 2 1 x RAID/HBA 16i + 1 x RAID/HBA 8i
12 0 0 0 0 4
1 or 2 OB SATA + 1 x RAID/HBA 8i
1 or 2 1 x RAID/HBA 16i
1 or 2 1 x RAID/HBA 16i + OB SATA
1 or 2 1 x RAID/HBA 16i + 1 x RAID/HBA 8i
12 0 0 0 4 0
1 or 2
OB SATA + 1 x RAID/HBA 8i
1 or 2 1 x RAID/HBA 16i
1 or 2 1 x RAID/HBA 16i + OB SATA
1 or 2 1 x RAID/HBA 16i + 1 x RAID/HBA 8i
12 0 4 0 0 4
2
OB SATA + 1 x RAID/HBA 8i
2 1 x RAID/HBA 32i
12 0 4 0 4 0
2
OB SATA + 1 x RAID/HBA 8i
2
1 x RAID/HBA 32i
12 0 0 8 0 0 2 1 x RAID/HBA 16i + OB NVMe
0 12 0 0 0 0
2
OB SATA + OB NVMe
2 1 x RAID/HBA 16i + OB NVMe
0 12 0 0 0 4
2
1 x RAID/HBA 16i + OB NVMe
2 1 x RAID/HBA 16i + 1 x RAID 8i + OB NVMe
0 12 4 0 0 4 2 1 x RAID/HBA 32i + OB NVMe
Chapter 3. Internal cable routing 161
