Table 30. Independent mode with two processors (DIMMs with different capacities) (continued)
24 DIMMs
1,
2
1 3 4 5 7 8 9 10 12 13 14 16
32 DIMMs
1,
2
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Configura-
tion
DIMM slots
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
4 DIMMs 19 21
8 DIMMs 19 21 28 30
16 DIMMs
1,
2
17 19 21 23 26 28 30 32
24 DIMMs
1,
2
17 19 20 21 23 26 28 29 30 32
32 DIMMs
1,
2
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
Notes:
1. DIMM configurations that support the Sub NUMA Clustering (SNC) feature, which can be enabled via
UEFI. SNC is not supported if DIMM population does not follow the sequence indicated by the table
above.
2. DIMM configurations that support Software Guard Extensions (SGX). See “Enable Software Guard
Extensions (SGX)” in Setup Guide to enable this feature.
