Lenze L-force 9400 Series Software Manual

9400 regenerative power supply module | Parameter setting
"CAN on board" system bus
Implemented CANopen objects
152 L EDS94ARNExxxx EN 2.3 - 06/2014
I-1011
Loading of Lenze setting.
 Corresponds to the device command C00002
= "0: Load Lenze setting".
 This command serves to reset the parameters of the active application to the Lenze
setting stored in the firmware.
Reading subindex 1
[6-5] Assignment of the data telegram (reading)
Writing to subindex 1
In addition to index and subindex, the telegram data must include the signature "load"
(ASCII characters; ISO 8859) to start the loading of the Lenze setting.
 A response according to the specification DS301 V4.02 occurs when a wrong identifier
is used for writing.
[6-6] Assignment of the data telegram (writing)
Index:
I-1011
Name:
Restore default parameters
Subindex Default setting Setting range (min. value | unit | max. value) Access Data type
0: Highest subindex supported 1 - (read access only) ro U32
1: Restore all default parameters - 0 4294967295 rw U32
Subindex Meaning
Reading Writing
0 Max. number of supported subindexes: 1 -
(A write attempt results in the error
message 0x06010002.)
1 Loading of all parameters is possible. Loading of Lenze setting.
8th byte 7th byte 6th byte 5th byte
Data 4 Data 3 Data 2 Data 1
Bit31...bit1 Bit 0
0 0/1
Bit Setting
Bit 0 0 Loading of parameters not possible.
1 Loading of parameter possible (Lenze).
8th byte 7th byte 6th byte 5th byte
Data 4 Data 3 Data 2 Data 1
"d" = 0x64 "a" = 0x61 "o" = 0x6F "l" = 0x6C
