Lenze L-force 9400 Series Software Manual

EDS94ARNExxxx EN 2.3 - 06/2014 L 151
9400 regenerative power supply module | Parameter setting
"CAN on board" system bus
Implemented CANopen objects
I-1010
Saving the parameters with mains failure protection.
 Corresponds to the device command C00002
= "11: Save start parameters".
 This command serves to store the current parameter settings of the active application
with mains failure protection in the memory module of the regenerative power supply
module.
Reading subindex 1
[6-3] Assignment of the data telegram (read access)
Writing to subindex 1
In addition to index and subindex, the telegram data must include the signature “save“
(ASCII characters; ISO 8859) to start the parameter saving (see table).
 A response according to the specification DS301 V4.02 occurs when a wrong identifier
is used for writing.
[6-4] Assignment of the data telegram (write access)
Index:
I-1010
Name:
Store parameters
Subindex Default setting Setting range (min. value | unit | max. value) Access Data type
0: Highest subindex supported 1 - (read access only) ro U32
1: Save all parameters - 0 4294967295 rw U32
Subindex Meaning
Reading Writing
0 Max. number of supported subindexes: 1 -
(A write attempt results in the error
message 0x06010002.)
1 Reading of the storing functionality of all
parameters.
Saving the parameters with mains
failure protection.
8th byte 7th byte 6th byte 5th byte
Data 4 Data 3 Data 2 Data 1
Bit31...bit2 Bit 1 Bit 0
00/1 0/1
Bit Meaning
Bit 0 0 Saving of parameters on command not possible.
1 Saving of parameters on command possible (Lenze).
Bit 1 0 Automatic saving of parameters not possible (Lenze).
1 Automatic saving of parameters possible.
8th byte 7th byte 6th byte 5th byte
Data 4 Data 3 Data 2 Data 1
"e" = 0x65 "v" = 0x76 "a" = 0x61 "s" = 0x73
