9400 regenerative power supply module | Parameter setting
"CAN on board" system bus
Implemented CANopen objects
158 L EDS94ARNExxxx EN 2.3 - 06/2014
Example
Parameter data channel 2 of the controller with node address 4 is to be activated.
For this purpose, bit 31 must be set to "0" (≡ "SDO is valid") in the subindexes 1 and 2 of
the I-1201
object.
The two "write request" commands must be sent from the master to the nodes via the
basic SDO channel.
Calculation of the identifiers
Identifier (COB-ID) = basic identifier + node address (node ID)
Basic identifier SDO2 from the master to the drive: 1600 (0x640)
Identifier = 0x640 + 0x4 = 0x644
Basic identifier SDO2 from the drive to the master: 1472 (0x5C0)
Identifier = 0x5C0 + 0x4 = 0x5C4
Resulting data (data 1 ... data 4)
[6-11] Assignment of the data telegram for subindex 1
[6-12] Assignment of the data telegram for subindex 2
Assignment of the user data
[6-13] Assignment of the user data for writing to subindex 1
[6-14] Assignment of the user data for writing to subindex 2
8th byte 7th byte 6th byte 5th byte
Data 4 Data 3 Data 2 Data 1
Bit 31 Bit 30 Bit 29 ... bit 11 Bit 10 ... bit 0
0 0 Extended identifier = 0 11-bit identifier = 0x644
0x00 0x00 0x06 0x44
8th byte 7th byte 6th byte 5th byte
Data 4 Data 3 Data 2 Data 1
Bit 31 Bit 30 Bit 29 ... bit 11 Bit 10 ... bit 0
0 0 Extended identifier = 0 11-bit identifier = 0x5C4
0x00 0x00 0x05 0xC4
1st byte 2nd byte 3rd byte 4th byte 5th byte 6th byte 7th byte 8th byte
Command Index Subindex Data 1 Data 2 Data 3 Data 4
0x23 0x01 0x12 0x01 0x44 0x06 0x00 0x00
1st byte 2nd byte 3rd byte 4th byte 5th byte 6th byte 7th byte 8th byte
Command Index Subindex Data 1 Data 2 Data 3 Data 4
0x23 0x01 0x12 0x02 0xC4 0x05 0x00 0x00
