Lenze L-force 9400 Series - Page 226

9400 regenerative power supply module | Parameter setting
Diagnostics & fault analysis
Error messages
226 L EDS94ARNExxxx EN 2.3 - 06/2014
DC bus overvoltage [0x007b000e]
DC bus undervoltage [0x007b000f]
Power control: Task overflow [0x007b0013]
Internal communication error (host MCTRL) [0x007b0014]
Feedback: Open circuit at X9 [0x007b001b]
Brake transistor: Ixt overload [0x007b001c]
Response (Lenze setting printed in bold) Setting: C00600 ( Adjustable response)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Since the braking energy is too high, the DC-bus voltage
is higher than the overvoltage threshold which results
from the mains setting in C00173
.
• Use brake resistor or regenerative module.
•Check setting under C00173
.
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
DC bus voltage is lower than the undervoltage threshold
resulting from the mains setting under C00173
.
• Check mains voltage.
•Check setting under C00173
.
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Internal error (control). Please contact Lenze.
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Internal error (control). Please contact Lenze.
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
• Mains detection cable interrupted.
• Mains detection defective.
• Check mains detection cable.
• Check mains detection.
Response (Lenze setting printed in bold) Setting: C00573 ( Adjustable response)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Too frequent and too long brake operations. Check drive dimensioning.
