Lenze L-force 9400 Series

9400 regenerative power supply module | Parameter setting
Parameter reference
Parameter list | C00571
314 L EDS94ARNExxxx EN 2.3 - 06/2014
C00571
C00572
C00573
C00574
Parameter | Name:
C00571 | Resp. brake resist. i2t > C00572
Data type: UNSIGNED_32
Index: 24004
d
= 5DC4
h
Response to be initiated when adjustable warning threshold (C00572) of brake resistor monitoring is reached.
Parameterising the brake chopper/brake resistor
Selection list (Lenze setting printed in bold)
1Fault
2Trouble
12 Trouble: chopper off
5 Warning
4 Warning locked
0 No response
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00572 | Warning thres. brake resistor
Data type: UNSIGNED_32
Index: 24003
d
= 5DC3
h
Warning threshold for brake resistor monitoring
• The response to be initiated when the threshold is reached can be selected in C00571
.
Parameterising the brake chopper/brake resistor
Setting range (min. value | unit | max. value) Lenze setting
0 % 100 90 %
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00573 | Resp. to overload brake trans.
Data type: UNSIGNED_32
Index: 24002
d
= 5DC2
h
Response triggered by brake chopper monitoring
Parameterising the brake chopper/brake resistor
Selection list (Lenze setting printed in bold)
1Fault
2Trouble
5 Warning
4 Warning locked
0 No response
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00574 | Resp. to overtemp. brake resist.
Data type: UNSIGNED_32
Index: 24001
d
= 5DC1
h
Response triggered by brake resistor monitoring
Parameterising the brake chopper/brake resistor
Selection list (Lenze setting printed in bold)
1Fault
2Trouble
12 Trouble: chopper off
5 Warning
4 Warning locked
0 No response
 Read access  Write access  CINH  PLC STOP  No transfer
