Lenze L-force 9400 Series Software Manual

EDS94ARNExxxx EN 2.3 - 06/2014 L 281
9400 regenerative power supply module | Parameter setting
Parameter reference
Parameter list | C00126
C00126
C00129
C00130
C00131
C00132
Parameter | Name:
C00126 | CPU temp. warning threshold
Data type: UNSIGNED_32
Index: 24449
d
= 5F81
h
Temperature threshold for advance warning of CPU temperature on the control card
• The response to be initiate when the threshold is reached can be selected in C00589
.
Setting range (min. value | unit | max. value) Lenze setting
0°C8570 °C
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00129 | Brake resistor value
Data type: INTEGER_32
Index: 24446
d
= 5F7E
h
Required for monitoring of the brake resistor temperature.
Parameterising the brake chopper/brake resistor
Setting range (min. value | unit | max. value) Lenze setting
0.0 Ohm 500.0 180.0 Ohm
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10
Parameter | Name:
C00130 | Rated power of brake resistor
Data type: INTEGER_32
Index: 24445
d
= 5F7D
h
Required for monitoring of the brake resistor temperature.
Parameterising the brake chopper/brake resistor
Setting range (min. value | unit | max. value) Lenze setting
0 W 800000 5600 W
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00131 | Therm. capacity brake resistor
Data type: INTEGER_32
Index: 24444
d
= 5F7C
h
Required for monitoring of the brake resistor temperature.
Parameterising the brake chopper/brake resistor
Setting range (min. value | unit | max. value) Lenze setting
0 kWs 100000 485 kWs
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00132 | Activation brake chopper
Data type: UNSIGNED_8
Index: 24443
d
= 5F7B
h
From software version V2.0 onwards
Setting the brake chopper activation
Selection list (Lenze setting printed in bold) Information
0Overvoltage
1 Overvoltage + overcurrent
2 Overvolt. + overcur. + util.
 Read access  Write access  CINH  PLC STOP  No transfer
