Lenze L-force 9400 Series

9400 regenerative power supply module | Parameter setting
Parameter reference
Parameter list | C00585
316 L EDS94ARNExxxx EN 2.3 - 06/2014
C00585
C00587
C00588
C00589
Parameter | Name:
C00585 | Resp. to filter PTC overtemp.
Data type: UNSIGNED_32
Index: 23990
d
= 5DB6
h
Response if filter temperature via PTC input T1/T2 is too high.
Selection list (Lenze setting printed in bold)
1Fault
5 Warning
0 No response
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00587 | Fan control status
Data type: BITFIELD_8
Index: 23988
d
= 5DB4
h
Value is bit-coded:
Bit 0 Heatsink fan ON
Bit 1 Integral fan ON
Bit 2 Heatsink fan status 1
Bit 3 Heatsink fan status 2
Bit 4 Integral fan status
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00588 | Resp. to failure t. sensor drive
Data type: UNSIGNED_32
Index: 23987
d
= 5DB3
h
Response to error/failure of temperature sensor for heatsink temperature/temperature inside the device
Selection list (Lenze setting printed in bold)
1Fault
5 Warning
0 No response
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00589 | Resp. to CPU temp. > C00126
Data type: UNSIGNED_32
Index: 23986
d
= 5DB2
h
Response if temperature of CPU on control card > variable limit temperature (C00126).
Selection list (Lenze setting printed in bold)
1Fault
5 Warning
0 No response
 Read access  Write access  CINH  PLC STOP  No transfer
