Lenze L-force 9400 Series Software Manual

9400 regenerative power supply module | Parameter setting
Parameter reference
Parameter list | C00133
282 L EDS94ARNExxxx EN 2.3 - 06/2014
C00133
C00134
C00137
C00138
C00142
Parameter | Name:
C00133 | Ref.: Brake chopper utilisation
Data type: UNSIGNED_8
Index: 24442
d
= 5F7A
h
Parameterising the brake chopper/brake resistor
Selection list (Lenze setting printed in bold) Information
0 Minimum resistance (C00134)  C00134
1 Resistance in C00129 C00129
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00134 | Minimum brake resistance
Data type: INTEGER_32
Index: 24441
d
= 5F79
h
Parameterising the brake chopper/brake resistor
Display range (min. value | unit | max. value)
0.0 Ohm 500.0
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10
Parameter | Name:
C00137 | Brake transistor utilisation
Data type: INTEGER_32
Index: 24438
d
= 5F76
h
Parameterising the brake chopper/brake resistor
Display range (min. value | unit | max. value)
0 % 250
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00138 | Brake resistor utilisation
Data type: INTEGER_32
Index: 24437
d
= 5F75
h
Parameterising the brake chopper/brake resistor
Display range (min. value | unit | max. value)
0 % 250
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00142 | Autom. restart after mains ON
Data type: UNSIGNED_32
Index: 24433
d
= 5F71
h
Starting performance of the device after power-on or after resetting a "trouble" or "fault".
Automatic restart after mains power-on
Selection list (Lenze setting printed in bold)
0Inhibited
1Enabled
 Read access  Write access  CINH  PLC STOP  No transfer
