9400 regenerative power supply module | Parameter setting
Parameter reference
Parameter list | C00150
284 L EDS94ARNExxxx EN 2.3 - 06/2014
C00150
C00155
Parameter | Name:
C00150 | Status word device control 1
Data type: BITFIELD_16
Index: 24425
d
= 5F69
h
Status word 1 of the device interface
Value is bit-coded: Information
Bit 0 Reserved For the meaning of bits 8 ... 11 see chapter "Device
states".
Bit 1 Pulse inhibit active
Bit 2 Reserved
Bit 3 Reserved
Bit 4 Reserved
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Controller inhibit active
Bit 8 Device state - Bit 1
Bit 9 Device state - Bit 2
Bit 10 Device state - Bit 3
Bit 11 Device state - Bit 4
Bit 12 Warning active
Bit 13 Trouble active
Bit 14 Reserved
Bit 15 Reserved
Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C00155 | Status word device control 2
Data type: BITFIELD_16
Index: 24420
d
= 5F64
h
Status word 2 of the device interface
Value is bit-coded:
Bit 0 Error status active
Bit 1 Reserved
Bit 2 Current limit reached
Bit 3 Reserved
Bit 4 Drive switched on/in operation
Bit 5 Drive ready for operation
Bit 6 Error active
Bit 7 Drive initialisation
Bit 8 Line rotates CCW
Bit 9 Reserved
Bit 10 Power regeneration blocked
Bit 11 Application active
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
Read access Write access CINH PLC STOP No transfer
