9400 regenerative power supply module | Parameter setting
Parameter reference
Parameter list | C00156
C00156
C00158
C00159
C00162
Parameter | Name:
C00156 | Status/Control word ECTRL
Data type: UNSIGNED_32
Index: 24419
d
= 5F63
h
Status and control word of the control system
Display range (min. value | unit | max. value)
0 4294967295
Subcodes Information
C00156/1 Status word DC-bus control
C00156/2 Control word DC-bus control
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00158 | Controller inhibit by (source)
Data type: BITFIELD_16
Index: 24417
d
= 5F61
h
Value is bit-coded:
Bit 0 Terminal
Bit 1 Reserved
Bit 2 Reserved
Bit 3 Reserved
Bit 4 Application
Bit 5 Controller command
Bit 6 Error response
Bit 7 Internal PLC
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Operating system
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00159 | Service code
Data type: BITFIELD_16
Index: 24416
d
= 5F60
h
This code is used internally by the device and must not be overwritten by the user!
Parameter | Name:
C00162 | Masked Error number
Data type: UNSIGNED_32
Index: 24413
d
= 5F5D
h
From software version V2.0 onwards
Display of the individual components of the error number under C00168
.
Display range (min. value | unit | max. value)
0 4294967295
Subcodes Information
C00162/1 Module + Error ID
• As described in the "Error messages
" chapter.
C00162/2 Instance ID
C00162/3 Response
 Read access  Write access  CINH  PLC STOP  No transfer
