Lenze L-force 9400 Series Software Manual

9400 regenerative power supply module | Parameter setting
Parameter reference
Parameter list | C00360
302 L EDS94ARNExxxx EN 2.3 - 06/2014
C00360
C00361
Parameter | Name:
C00360 | CAN telegram and error counter
Data type: UNSIGNED_16
Index: 24215
d
= 5E97
h
• After power-on, counting starts with "0".
• After the maximum value has been reached, counting restarts with "0".
"CAN on board" system bus
Display range (min. value | unit | max. value)
0 65535
Subcodes Information
C00360/1 Stuffing bit error counter
• More than five identical bits have been detected.
C00360/2 Format error counter
• CAN frame has not been complied with.
C00360/3 Acknow. error counter
• No device has acknowledged the telegram.
C00360/4 Bit 1 error counter
• "1" should be sent after bus arbitration, but "0" was
read.
C00360/5 Bit 0 error counter
• "0" should be sent after bus arbitration, but "1" was
read.
C00360/6 CRC error counter
• Check sum check has indicated an error.
C00360/7 Tx telegram counter
• Correctly received telegrams.
C00360/8 Rx telegram counters
• Correctly transmitted telegrams.
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C00361 | CAN bus load
Data type: UNSIGNED_32
Index: 24214
d
= 5E96
h
Switch off the device and then on again or use the device command "Reset node" (C00002) to reset the display of
the maximum node load (subcodes 4 ... 6).
"CAN on board" system bus
Display range (min. value | unit | max. value)
0 % 100
Subcodes Information
C00361/1 Current node load in Tx direction
C00361/2 Current node load in Rx direction
C00361/3 Current node load through faulty telegrams
C00361/4 Maximum node load in Tx direction
C00361/5 Maximum node load in Rx direction
C00361/6 Maximum node load through faulty telegrams
 Read access  Write access  CINH  PLC STOP  No transfer
