Lexmark CX310dn - Narrow Media Sensor Service Check

Narrow media sensor service check
Actions Yes No
Step 1
Open the front cover, and inspect the narrow media sensor (A) located
towards the front of the top cover assembly.
Is the narrow media sensor dislodged or damaged?
Repair or replace the
narrow media sensor.
See “Narrow media
sensor removal” on
page 280.
Go to step 2.
Step 2
Does the flag rotate freely?
Go to step 3. Reposition or replace
the flag. See “Narrow
media sensor
removal” on page
280.
7527
Diagnostic information
113
