Lexmark CX310dn - Front Middle Cover Removal; Left Cover Assembly Removal

Front middle cover removal
1 Open the front cover.
2 Remove the five screws (A) attaching the front middle cover to the lower front cover.
3 Pull the front middle cover away from the front cover to remove.
Left cover assembly removal
1 Remove the two screws (A) from the rear of the printer.
7527
Repair information
219
